Product Specifications
View Production Capabilities
Get information on the product we offer with a variety of options including: Conduit Types, Available Sizes, Wall Types, Color Offerings, and Optional Items like Pre-Installed Pull-Tape.
See our full capabilities below, download our spec sheet, or request a quote for your business!
STANDARD CONDUIT
Conduit Types
Smooth Wall
Interally Ribbed
Available Sizes
.75″, 1″, 1.25″, 1.5″, 2.0″
1.25″, 1.5″, 2.0″
Wall Types
SDR 11, SDR 13.5
SDR 11, SDR 13.5
Optional: Pre-Installed Pull Tape – 1/2” 1250 lb
Colors
MATERIAL: PRIME HIGH DENSITY POLYETHYLENE (DOW DGDA-2488 & BRASKEM HDPE0353)
Desicription:
Dow DGDA-2488 & Braskem HDPE0353 are HDPE copolymers designed for solid wall conduit applications
Industrial Standard compliance ASTM D3350: Cell Classification PE 435620A
Dow DGDA-2488 and Braskem HDP0353 meet the material requirements specifications ASTM F2160 and SUDAS Spec 8010.2.01
The resin is recommended for use in applications that are required to meet AASHTO M294 Specifications
Applications:
Natural bimodal high density polyethylene copolymer resin designed for small and large telecom conduit
Control Properties:
| FEATURE | METHOD | UNITS | BRASKEM | DOW |
|---|---|---|---|---|
| Melt Flow Rate (190°C/2.16kg) | ASTM D1238 | g/10 min | 0.35 | 0.28 |
| Density | ASTM D792 | g/cm³ | 0.953 | 0.954 |
Typical Properties:
| FEATURE | METHOD | UNITS | BRASKEM | DOW |
|---|---|---|---|---|
| Tensile Strength at Yield | ASTM D638 | MPa | 26 | 22.8 |
| Tensile Strength at Break | ASTM D638 | MPa | 38 | 31.7 |
| Strain at Break | ASTM D638 | % | 665 | 750 |
| Flexural Modulus (Secant 1%) | ASTM D790 | MPa | 1275 | 1000 |
Conduit Dimensions:
| CONDUIT SIZE | OD | OD TOLERANCE (+/-) | WALL THICKNESS | WALL THICKNESS TOLERANCE (+) | MAX WALL THICKNESS |
|---|---|---|---|---|---|
| 0.75” SDR 11 | 1.050 | 0.005 | 0.095 | 0.020 | 0.115 |
| 1.0” SDR 11 | 1.315 | 0.007 | 0.120 | 0.020 | 0.140 |
| 1.25” SDR 11 | 1.600 | 0.008 | 0.151 | 0.020 | 0.171 |
| 1.5” SDR 11 | 1.900 | 0.010 | 0.173 | 0.021 | 0.194 |
| 2” SDR 11 | 2.375 | 0.012 | 0.216 | 0.026 | 0.242 |
| 0.75” SDR 13.5 | 1.050 | 0.005 | 0.078 | 0.020 | 0.098 |
| 1.0” SDR 13.5 | 1.315 | 0.007 | 0.097 | 0.020 | 0.117 |
| 1.25” SDR 13.5 | 1.660 | 0.008 | 0.123 | 0.020 | 0.143 |
| 1.5” SDR 13.5 | 1.900 | 0.010 | 0.141 | 0.020 | 0.161 |
| 2”’ SDR 13.5 | 2.375 | 0.012 | 0.176 | 0.020 | 0.196 |
REEL RETURN PROGRAM
Locate reels that meet the Acceptable Guidelines and return them for cash. Reusing steel reels is environmentally friendly and cleans up the work area. Reels in good condition can be sent back to Conduit Direct Group for reuse.
